Customized Stainless Steel Spiral Sand Washer with 40-280 tons/hour Capacity for Efficient Gravel Washing

ブランド名:	WeSeW
モデル番号:	カイ001
MOQ:	1pcs
価格:	US$20,000~US$80,000 per pc
支払条件:	T/T、ウェスタンユニオン
供給能力:	1か月あたり10000pc

詳細情報

製品説明

詳細情報

起源の場所:

中国

証明:

CE,UL

材料:

ステンレス鋼/カスタム

材料機能:

耐熱性、耐火性

応用:

化学産業、穀物輸送、鉱業輸送、発電所

コアコンポーネント:

モーター

寸法（l*w*h）:

カスタマイズ

仕様:

カスタマイズ

構造:

コンベアシステム

パッケージの詳細:

木製のケース

供給の能力:

1か月あたり10000pc

ハイライト:

Customized Spiral Sand Washer

Stainless Steel Screw Sand Washing Machine

40-280 tons/hour Sand Screw Washer

製品説明

Customized Single Spiral Aggregate Sand Gold Washing Machine

Our industrial-grade Spiral Sand Washing Machine efficiently cleans and separates dirt, dust, and impurities from sand, gravel, or crushed stone. Utilizing a rotating screw mechanism with water flow, it delivers high-quality washed materials for construction, mining, and aggregate applications.

Key Features

High cleaning efficiency: Removes dirt, clay and organic impurities effectively
Low water consumption: Environmentally friendly operation
Robust construction: Made of wear-resistant steel for durability
Energy efficient: AC motor with ISO9001 & CE certifications
Comprehensive support: 1-year warranty with lifetime spare parts supply

Technical Specifications

Product Name	Industrial Spiral Screw Classifier Sand Washing Machine
Motor Type	AC Motor
Capacity	6-400t/h
Core Components	Bearing, Gearbox, Motor
Weight	500 KG
Applications	Motorway construction, hydropower projects, building material washing, classification

Detailed Technical Parameters

Model	Spirals Number	Screw Diameter (mm)	Sink Length (mm)	Capacity (t/h)	Motor Power (kw)
XL920-7.5	1	920	3600	40-60	4P-11
2XL920-7.5	2	920	7500	90-120	4P-11X2
XL1120-7.5	1	1120	5000	40-120	4P-18.5
2XL1120-7.5	2	1120	10000	80-240	4P-18.5X2
XL1500-9	1	1500	9800	100-170	4P-22
2XL1500-9	2	1500	18000	200-280	4P-22X2

Working Principle

The Spiral Sand Washer operates through a synergistic process of agitation, settling and material transportation. As the sand-cement slurry enters the inclined trough, the rotating spiral blades agitate the mixture while gravity settles heavier sand particles. Lighter impurities remain in suspension and are washed away by water flow. The spiral simultaneously conveys the cleaned sand up the slope while discharging excess water through tank holes.
